Lenovo P5520, 3,84 TB, 2.5"
Lenovo P5520. SSD capaciteit: 3,84 TB, SSD-vormfactor: 2.5", Component voor: Server
Kenmerken
| SSD capaciteit | 3,84 TB |
| SSD-vormfactor | 2.5" |
| Interface | PCI Express 4.0 |
| NVMe | Ja |
| Type geheugen | 3D TLC NAND |
| Component voor | Server |
| Random read (4KB) | 1000000 IOPS |
| Random write (4KB) | 200000 IOPS |
| Willekeurige latentie - lezen (tot) | 75 µs |
| Willekeurige latentie - schrijven (tot) | 15 µs |
| Sequentiële latentie - lezen (tot) | 10 µs |
| Sequentiële latentie - schrijven (tot) | 13 µs |
| S.M.A.R.T. support | Ja |
| Hot-swap | Ja |
| Uncorrectable Bit Error Rate (UBER) | |
| Mean time between failures (MTBF) | 2000000 uur |
| Drive writes per dag (DWPD) | Ja |
| Certificering | FCC Title 47, Part 15B, Class B CA/CSA-CEI/IEC CISPR 22:02 EN 55024: 1998 EN 55022: 2006 EN-60950-1 2nd Edition UL/CSA EN-60950-1 2nd Edition Low Voltage Directive 2006/95/EC C-Tick: AS/NZS3584 BSMI: CNS 13438 KCC Article 11.1 RoHS DIRECTIVE 2011/65/EU WEEE Directive 2002/96/EC |
Energie
| Stroomverbruik (lezen) | 15 W |
| Stroomverbruik (schrijven) | 15 W |
Gewicht en omvang
| Breedte | 70 mm |
| Diepte | 100 mm |
| Hoogte | 15 mm |
| Gewicht | 146 g |
Eisen aan de omgeving
| Bedrijfstemperatuur (T-T) | 0 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 90 procent |
| Trillingen, in bedrijf | 2,17 G |
| Schokbestendigheid | 1000 G |
| Maximale hoogte, in gebruik | 3048 m |
Overige specificaties
| Uithoudingsrating | 7 PB |
